Items | WNS0.5- 0.7-Y(Q) | WNS1- 0.7-Y(Q) | WNS2- 0.1-Y(Q) | WNS5- 1.25-Y(Q) | WNS8- 1.6-Y(Q) | WNS10- 1.6-Y(Q) | |||||
Nominal Capacity (t/h) | 0.5 | 1 | 2 | 5 | 8 | 10 | |||||
Nominal Working Pressure | 0.7 Mpa | 0.7 Mpa | 1.0 Mpa | 1.25 Mpa | 1.6 Mpa | 1.6 Mpa | |||||
Saturated Steam Temperature | 170 | 170 | 184 | 194 | 204 | 204 | |||||
Thermal Efficiency of Boiler | 92% | 92% | 92% | 92.3% | 92% | 92% | |||||
Nominal Oil and Gas Consumption (Nm3/h) | 34.5/42 | 68.5/82 | 134/162 | 330/371 | 524/589 | 656/737 | |||||
Power Consumption (KW) | 2.96(2.96) | 4.4/8.9 (3.7) | 7/20.2 (7) | 14.5/28 (15) | 24/37.5 (24) | 39.5/52 (39.5) | |||||
Applicable Fuel | Light oil or heavy oil Natural gas or city gas | ||||||||||
Power Supply (AC) | 380v 50Hz | ||||||||||
Weight and Size of maximum transport thing (m) | 3.1*1.9* 1.9 | 4.35*2.5*2.33 | 4.17*2.1*2.96 | 5.30*2.40*3.27 | 6.01*2.90*3.37 | 6.86*2.90 *3.37 | |||||
Approx. Weight of maximum transporting thing kg | 4000 | 5800 | 6600 | 13500 | 20000 | 24500 | |||||
Exhaust Gas Temperature (°C) | 230 | 230 | 230 | 230 | 230 | 230 | |||||
Combustion way | Pressure atomized Micro positive pressure combustion | ||||||||||
Regulating mode | Automatic | ||||||||||
